Huatao offer anti-stick teflok roller and solve your life time problem with best solution and good maintenance is helpful to prolong the life time
When using a Teflok roller for work, if there is a conflict between the Teflon roller and the pressed material, static electricity will be occurred , which will suck dust in the air to the surface of the Teflok roller. So you will be found that there are a lot of foreign objects on the roller surface. At this time, you need to use a soft cloth to wipe the Teflon roller gently to achieve the purpose of improving the appearance quality of the Teflon roller.
When installed on equipment for production, whenever materials enter the working surface of the Teflok roller. The material needs to be calendered first to avoid scratches on the roller surface due to rapid hardening of the material. Of course, this operation must be performed without affecting the production quality of the material. If it affects the exit of the material, it needs to be polished at the Teflok roller factory.
There are two kinds of Teflok coating roller :MDO Teflok Preheating Roller & Teflok MDO stretching rollers used in the production process of the BOPP BOPET/BOPA/Optical/Battery Separator film production line，the common film line width : 6.6M, 6.3m 8.7 m,10.6m .10.5 10.4m the teflok Preheating roller size :φ595 * FL1200, φ614*FL1200 ，the teflok MDO stretching Roller size of BOPET Line : φ220/230*2800 ， 230*2900 ，φ232*2900
Shell: Double-shell construction
Disc/Shaft: Shrinked and welded shafts and side discs from Q345B
Flow-system: Flow channels between inner and outer tube separated with welded leading spirals
Water / oil inlet and outlet at same end
Surface coating: Teflon / ceramic / chroming / tungsten carbide
Surface
TEF-Lok coated, roughness Ra<=0.4um， coating thickness:60-100um
Static and dynamic requirement, tolerances
Runout <=0.05mm，cylindricity <=0.05mm
Dynamic balancing G2.5 up to max. line speed
Now you should learn how to learn maintain the teflok coating roller and the teflon coating roller used in in the film production;
If you have any concern about the teflok coating MDO stretching roller or Preheating roller or other roller used the in Film Casting/MDO/PRS/Winding/Coating/Metalizer etc。
Chill Roller ,MDO Preheating Roller ,MDO Stretching Roller,MDO nip roller, Cooling Roller,Corona Treater Roller, Corona Treatment Nip Roller, Flame Roller,Carbon Fiber contact roller, Carbon fiber Transition Roller, Carbon Fiber Slitter Roller, Spreader Roller,Stripping Roller, Watertank Fluted Roller,Dehydration Press Roller
